Pendent Quick and Standard Response K8.0 Fire Sprinkler Price

Basic Info

Model NO.	ZSTX-20
Dry Alarm Valve Type	Differential Type
Wet Alarm Valve Structure	Seat Type
Alarm Valve Diameter	100mm
Nozzle Flow Coefficient	80
Deluge Valve Type	Diaphragm Type
Product Name	K8.0fire Sprinkler
Finish	Chrome; Original
Connection	3/4′′; Bsp/NPT
Material	Brass
Temperature	57-141degree
OEM	Workable, MOQ=5000PCS
Listings and Approvals	Cccf, ISO9001, ISO14001
Transport Package	Carton
Specification	48.5*25*33.5
Trademark	FOREDE
Origin	Fujian, China
HS Code	8424901000
Production Capacity	200000sets/Month

Product Description

K=5.6/8.0 FIRE SPRINKLER

A fire sprinkler or sprinkler head is the component of a fire sprinkler system that discharges water when the effects of a fire have been detected, such as when a predetermined temperature has been exceeded. Fire sprinklers are extensively used worldwide, with over 40 million sprinkler heads fitted each year. In buildings protected by properly designed and maintained fire sprinklers, over 99% of fires were controlled by fire sprinklers alone.

FeaturesK FACTOR:K [email protected] US([email protected])Thread Size:DN20(3/4'')Connecting Thread: BSP (NPT Optional)Main Material: BrassSensitive Element: YF® Brand Glass Bulb (JOB® Glass Bulb Optional);Seal Material: NBRSurface Finishing : Chrome (Natural Brass Optional).

Model Number	Size	K factor	Tempurature	Response Type	Glass Bulb
T-ZSTX-20-57ºC	3/4''(DN20)	8.0	57ºC	Standard	5mm,Orange
T-ZSTX-20-68ºC	3/4''(DN20)	8.0	68ºC	Standard	5mm,Red
T-ZSTX-20-79ºC	3/4''(DN20)	8.0	79ºC	Standard	5mm,Yellow
T-ZSTX-20-93ºC	3/4''(DN20)	8.0	93ºC	Standard	5mm,Green
T-ZSTX-20-141ºC	3/4''(DN20)	8.0	141ºC	Standard	5mm,Blue
K-ZSTX-20-57ºC	3/4''(DN20)	8.0	57ºC	Quick	3mm,Orange
K-ZSTX-20-68ºC	3/4''(DN20)	8.0	68ºC	Quick	3mm,Red
K-ZSTX-20-79ºC	3/4''(DN20)	8.0	79ºC	Quick	3mm,Yellow
K-ZSTX-20-93ºC	3/4''(DN20)	8.0	93ºC	Quick	3mm,Green
K-ZSTX-20-141ºC	3/4''(DN20)	8.0	141ºC	Quick	3mm,Blue

Detailed Photos

Packaging & Shipping

FAQ

Q.What's your payment terms?

A:We accept T/T, L/C, Western Union, Paypal,etc.

Q. How long is the delivery time?
A: Usually around 15 days after payment.

Q.Do you have technical support?
A: Yes, we have a professional engineering team.

Q.Do you have warranty?
A:Yes, all products have one year warranty.

Q.Can you accept OEM?
A:Yes, we do customized design for our clients

Order InformationDear Customer,
Before ordering, please contact with our sales team to discuss order information.
If you have any other requirements or wanna know more info about our products, welcome to contact as well. Our Sales team and Technical Department are willing to support you.
